Rear Seat Armrest Replacement

Fold Down/Split Fold Down - For Some Models

1.	Remove the clip (A) from the left portion of the armrest pivot (B).

2.	Slide the armrest (A) toward the driver's side of the vehicle, and remove the pivot shaft (B) from the collar (C) on the right side of the vehicle by pulling back on the armrest.

3.	Remove the pivot shaft (A) from the collar (B) on the left, then remove the armrest (C).

4.	Remove the collars (A) from the seat-back (B).

5.	Install the armrest in the reverse order of removal.

Fixed - For Some Models

1.	Remove the seat-back.

2.	Remove the clips (A) and the insulator (B) from behind the seat-back (C).

3.	Release the clips (A) fastening the armrest back cover (B).

4.	Pull the edge of the armrest back cover (A) up through a gap between the armrest (B) and the seat-back frame (C), then turn over the cover.

5.	Remove the bolts, then remove the armrest (A).

6.	Install the armrest in the reverse order of removal. Replace any clips you removed with new ones. Install them with commercially available upholstery ring pliers.
