| 1. | Support the engine with a jack and a wood block under the oil pan. |
| 2. | Remove the bolt (A) securing the A/C line, then remove the upper torque rod (B). M/T A/T |
| 3. | Remove the ground cable (A), then remove the side engine mount bracket (B).
|
| 4. | Remove the side engine mount stiffener (A), then remove the side engine mount (B).
|
| 5. | Install the side engine mount, then install the side engine mount stiffener. |
| 6. | Install the side engine mount bracket (A), then loosely tighten the new bolt and nut (B). Loosely tighten the bolt (C).
|
| 7. | Install the ground cable. |
| 8. | Remove the air cleaner housing assembly. |
| 9. | Loosen the transmission mounting bolt and nuts (A). M/T A/T |
| 10. | Raise the hoist to full height. |
| 11. | Loosen the lower torque rod mounting bolt (A).
|
| 12. | Lower the vehicle on the hoist. |
| 13. | Tighten the side engine mount mounting bolts and nut.
|
| 14. | Tighten the transmission mounting bolt and nuts. M/T A/T |
| 15. | Raise the hoist to full height. |
| 16. | Tighten the lower torque rod mounting bolt.
|
| 17. | Lower the vehicle on the hoist. |
| 18. | Install the air cleaner housing assembly. |
| 19. | Install the upper torque rod, then tighten the new upper torque rod mounting bolts in the numbered sequence shown. M/T A/T |
| 20. | Install the bolt (B) securing the A/C line. |
