Fuel and Emissions System Description - Vacuum Lines (K20Z)
Fuel and Emissions System Description - Vacuum Lines
Vacuum Hose Routing
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE VALVETo EVAPORATIVE EMISSION (EVAP) CANISTERINTAKE AIR BYPASS CONTROL THERMAL VALVEFRONT OF VEHICLE
Vacuum Distribution
3ENGINE COOLANT10619478921202517161214152411222513ATMOSPHERE1ENGINE COOLANT2318(1)(2)(3)(4)(5)(6)(7)(8)(9)(10)(11)(12)(13)(14)(15)(16)(17)(18)(19)(20)(21)(22)(23)(24)(25)AIR FUEL RATIO (A/F) SENSOR (SENSOR 1)SECONDARY HEATED OXYGEN SENSOR (SECONDARY HO2S) (SENSOR 2)MANIFOLD ABSOLUTE PRESSURE (MAP) SENSORENGINE COOLANT TEMPERATURE (ECT) SENSOR 1MASS AIR FLOW (MAF) SENSOR and INTAKE AIR TEMPERATURE (IAT) SENSORCRANKSHAFT POSITION (CKP) SENSORKNOCK SENSORCAMSHAFT POSITION (CMP) SENSOR BCAMSHAFT POSITION (CMP) SENSOR ATHROTTLE BODYINJECTORFUEL PRESSURE REGULATORFUEL FILTERFUEL PUMPFUEL TANKAIR CLEANERRESONATOREXHAUST GAS RECIRCULATION (EGR) VALVE and POSITION SENSORPOSITIVE CRANKCASE VENTILATION (PCV) VALVETHREE WAY CATALYTIC CONVERTEREVAPORATIVE EMISSION (EVAP) CANISTER PURGE VALVEEVAPORATIVE EMISSION (EVAP) CANISTERINTAKE AIR BYPASS CONTROL THERMAL VALVEFUEL TANK VAPOR/LIQUID SEPARATION VALVEEVAPORATIVE EMISSION (EVAP) TWO WAY VALVE
